ABS Plastic Optical Fiber Distribution Cabinet 4 Fiber With Indoor Mounted

Name: ABS Plastic Optical Fiber Distribution Cabinet 4 Fiber With Indoor Mounted
Brand: FOCABLE
Price: 1 USD

Brand Name : FOCABLE

Model Number : OTB-C04-D

Certification : RoHS Compliant, ISO Certificate

Place of Origin : China

MOQ : 50PCS

Payment Terms : Western Union, T/T

Supply Ability : 5000PCS/MONTH

Packaging Details : 1PCS/BOX

Mount type : Wall Mount, Pole Mount

Material : ABS Plastic

Port : 2, 4, 6, 8, 12, 24, 32, 48, 72, 96 Port

Connector : SC, FC, LC, ST, E2000

Contact Now

Fiber Termination Box 4 Core For Fiber Network Terminal Distribution Indoor Mounted

Fiber optic terminal box is used as a termination point for the feeder cable to connect with drop cable. The fiber splicing, splitting, distribution can be done in this box, and meanwhile it provides solid protection and management for the FTTx network building.

This fiber optic termination box offers the possibility to manage the splicing and the connection of four fibers via 4pcs SC simplex adapters, this capacity can be doubled with the use of LC duplex adapters. It is equipped with a splice area where the splices can be housed in total safety and the fibers can be orderly managed.

Features

Material: ABS plastic

Small, light weight and reasonable enclosed structure.

Used for fiber splicing, fixation, storage, distribution…etc.

Suitable for SC, LC, FC, ST ... etc. adapters

Indoor wall mounted application.

Application

Telecommunications subscriber loop

Fiber to the home (FTTH)

LAN/WAN

CATV

Specifications

Working Temperature: -40℃～+85℃

Insertion Loss: ≤0.2dB

Return Loss UPC: ≥50dB

Return Loss APC: ≥60dB

Durability: ≤0.3dB(1000 matings)

Description	OTB-C04-D
Dimensions(W×D×H)	165.73x90x24.1mm
Adapter port	4pc SC simplex
Splice capacity	Max. 4 fiber
Cable port	4pc FTTH drop cable port
Max. capacity of splitter	Can load 1pc PLC 1:4 steel tube type splitter
Color	White
Main body material	Plastic(ABS)
Installation type	Indoor wall mounting

ABS Plastic Optical Fiber Distribution Cabinet 4 Fiber With Indoor Mounted

Fiber Optic Terminal Box, Optical Termination Box, Plastic Terminal Box
