Outdoor Fiber Optic Patch Cord Armored SMA Black Jacket UV Resistant FTTH Use
Outdoor armored fiber optic patch cord SMA-SMA can be deployed directly in different harsh environment, without additional tube for protection, save space, reduce construction cost and make the maintenance more conveniently. Furthermore, the outdoor armored cable has the coated steel tape inside and parallel reinforcing steel wire to prevent optical fiber from damage, which improves security and stability of the system. The jacket of outdoor cable is PE sheath.
FOC COMMUNICATION CO., LTD can offer all types of fiber optic patch cord, including indoor common patch cord, indoor armored patch cord, outdoor armored patch cord, outdoor non-armored patch cord.
FOC COMMUNICATION CO., LTD has established a production base of patch cords therefore besides various connectors and corresponding adapters we can make jumpers as requested based on different cables. Our product comes in many types such as simplex, duplex, multi-core bunchy and ribbon types. Up to now ,we own about several years of production experience and we provide patch leads with high quality and at a reasonable price for over 300 enterprises at home and abroad.
Features
Prevent optical fiber from destroy by harsh environment
Prevent optical fiber from destroy by improper operation
Coated steel tape and steel wire for protection
High resistance of tensile strength, pressure and rodent bite
Without damage by construction
Ensure transmission power and avoid additional attenuation
Application
Optical Fiber Communications,Video,LAN, CATV Systems
Optical Network Equipments,optical Test Equipments
Module Pigtails,Multi media,Premise
Active device termination installations
SPECIFICATIONS
| | Single mode | Multimode |
| Insertion Loss | Typical <=0.2dB, Maximum<=0.3dB | ≤0.25dB |
| Return Loss | ≥50 dB (PC)
≥60 dB (APC) | |
| Repeatability | ≤0.1 | |
| Durability | ≤0.2 dB typical change, 1000 matings | |
| Interchangeability | ≤0.2dB | |
| Tensile strength | >70N | |
| Operating Temperature | -20 to + 70°C | -20 to + 70°C |
ORDERING OPTIONS
| Connector Color | Boot (cable) Size | Boot Color | Fiber Type | Cable number | Application | Length |
| Beige | 0.9mm | Beige | 9/125μm (SM) | Simplex | PC | Customized |
| Blue | 2.0mm | Black | 50/125μm(MM) | Duplex | APC | |
| Green | 3.0mm | Blue | 62.5/125μm(MM) | Fan-out (4f) | | |
| | | Green | | Fan-out (6f) | | |
| | | Gray | | Fan-out (8f) | | |
| | | Red | | Fan-out (12f) | | |
| | | White | | | | |
